Product Details
- Size: 1010*1140*2655mm
- Place of Origin: China,Shandong
- Brand Name: JIAODUAN
- Model Number: DXDC10
- Weight: 3640.000 kg
| Machine speed | 120±10bag/min |
| Capacity | Max.10 cm3 |
| Degree of accuracy | ±5% |
| Power supply | 3Phases, 380V, 50Hz |
| Power | Total power 10KW, Max. power 8KW |
| Weight | Max. 4250kg |
| Dosage system | Protection structure which keeps impurity away |
| Filter bag (naked bag) | Double chamber, bag size is 40x60mm. The max. external diameter of filter paper roll is 500mm, the inner diameter of filter paper roll is 75mm |
| Thread length | 140±5mm |
| Hard tab | 28x32mm, cutting on machine |
| The max. external diameter of envelope | roll is 500mm, and the inner diameter is 152mm |
| Staple | length 5mm after folded, magaluma staple |
| Machine size | Max. 3500x2400x1500mm |
