Description:

Tea-bag Packing Machine is an automatic precision machine use for packing broken tea and similar herbs into small bags and realize fully automatic procedure including ration filling, heat-sealing of tea bag, pasting thread, linking tag, envelope sealing, dividing groups and counting tea bag. Our company has developed multi-types of Tea-Packing Machine which based on advanced technology in the domestic and overseas trade and has reached the same level of imported equipment; furthermore some performances have exceeded this level.

Tea bag packing machine Model DXDC8I has an automatic boxing device instead of an envelope packing system.

Technical data:

1) Max. output: 120bags/minute
2) Max. dosage: 8cm³
3) Bag dimensions: 62.5 X 50mm
4) Tag dimensions: 28 X 24mm
5) Thread length: 210mm
6) Packing in boxes:
     a) 25, 50, 100
     b) 30, 60
     c) 20, 40
7) Power supply: AC 380V
8) Total power: 1.25kW
9) Weight: 540kg
10) Overall dimensions: 1.7 X 0.9 X 2m
11) Packing: 1pc/carton
Carton dimensions: 1.236 X 1 X 1.855m
