- Size: 1010*1140*2655mm
- Place of Origin: China,Shandong
- Brand Name: JIAODUAN
- Model Number: J53A-63
- Weight: 3640.000 kg
1.Use, Scope of use and feature
This press is a special pressing device and can be widely used all kinds of pressing industries. In machinery industry, it can finish blanking, bending, correction, precision pressing and punching in forging process.
The press has all purpose in use, simple in structure, assembly operation and auxiliary equipment and its price is lower, so it can be widely used in pressing shop, forging shop and die forging shop for machinery manufacturing, etc.
The press has the following characteristics:
1) The press adopts hand control ,and its operation has sensitive and reliable
2) There is the cushion equipment under the crossbeam ,when the brake is out of order ,it can reduce impact to protect the device.
2.Technical Specifications
1) Nominal pressure 630kN
2) Energy of moment 2250J
3) Min. closed height 315mm
4) Stroke of slide 200mm
5) Stroke times of slide 35/min
6) Working table dimensions (L.R. x F.B.) 270mmx315mm
7) Thickness of bolster for table 80mm
8) Bottom surface of slide(L.R. x F.B.) 227mm×275mm
9) stroke of ejecting 50mm
10)Upper and diameter of ejector bar 40mm
11)Power of motor 5.5kw
12)Mainweight 3640kg
