- Size: 21cbm
- Place of Origin: qingdao,shandong province
- Brand Name: JIAODUAN
- Model Number: J58K-300
- Weight: 16000.000 kg
1.Application and feature
This press is a special pressing device and can be widely used all kinds of pressing industries. In machinery industry, it can finish blanking, bending, correction, precision pressing and punching in forging process.
2.Introduce of J58K Screw Press with direct electric Drive
Screw Press with direct electric Drive has the shortest transmission chain and the very high efficiency, and at present, develops gradually by internationally using the Frequency control electric Motor, AC servo Motor, Motor, Switched Reluctance Motor in Screw Press with direct electric Drive.
3.Technique parameters:
Main parameters | unit | J58K-400 | J58K-630 | J58K-800 | J58K-1000 | J58K-1600 | J58K-2500 | J58K-4000 | |
Nominal pressure | KN | 4000 | 6300 | 8000 | 10000 | 16000 | 25000 | 40000 | |
Maximum pressure | KN | 6400 | 10000 | 12500 | 16000 | 25000 | 40000 | 63000 | |
Energy | KJ | 40 | 80 | 100 | 160 | 280 | 500 | 850 | |
Slide stroke | mm | 400 | 500 | 500 | 550 | 650 | 700 | 750 | |
Max blowing speed | m/s | 0.7 | 0.7 | 0.7 | 0.7 | 0.65 | 0.65 | 0.65 | |
Stroke per minute | times/min | 24 | 20 | 20 | 16 | 12 | 11 | 10 | |
Space for installing die | mm | 480 | 600 | 600 | 700 | 800 | 920 | 1060 | |
Bottom of slide | F/B | mm | 760 | 920 | 920 | 1000 | 1250 | 1400 | 1600 |
L/R | mm | 680 | 690 | 690 | 800 | 930 | 1240 | 1400 | |
Dimension of working table | F/B | mm | 820 | 920 | 920 | 1000 | 1250 | 1400 | 1600 |
L/R | mm | 730 | 800 | 800 | 900 | 1000 | 1400 | 1600 | |
H | mm | 120 | 180 | 180 | 180 | 200 | up1180/down240 | up200/down280 | |
Overall dimension | F/B | mm | 1900 | 3000 | 3000 | 2300 | 3240 | 4800 | 6000 |
L/R | mm | 3200 | 2700 | 2800 | 2500 | 3695 | 4800 | 6000 | |
H | mm | 4500 | 5600 | 5700 | 6600 | 7055 | 8350 | 10500 | |
Motor power | kw | 55 | 90 | 110 | 132 | 2X132 | 2X160 | 2X220 | |
Weight | kg | 26500 | 46000 | 50000 | 75000 | 135000 | 280000 | 400000 |
4.Structure Explanation
This press consists of frame, drive, flywheel, slide, operation, brake, lubrication, electric, foundation ,etc.
